Model No: CABINT-215KWh
Seplos TUV 215Kwh Lithium Iron Phosphate LiFePO4 Distributed ESS Cabinet Energy Storage Systems
If you want wholesale price, please do not hesitate to contact us.
minimum order :
1 unit
Supply Ability :
10000unit / Month
Stock Time :
15-20Day
Country of Origin :
China
Quantity :
This is Seplos 215kwh Distributed ESS Cabinet Energy Storage Systems. Which can provide reliable power for several types of equipment and systems. Come with the function of peak shaving. Configurate with CE TUV certification of PCS, fire fighting system, and Liquid cooling system.
The cabinet is scalable and can expand the power range from 215kwh to 1075kwh.
Parameter
| Item | Values |
System Parameter | |
DC side voltage rage | 600V~876V |
Output voltage | 380V@AC |
System configuration | 1P240S |
Rated power | 100kW |
Match PCS | 100kW |
Nominal energy of the battery system | 215kWh |
Discharge energy | ≥200kWh |
Battery cycle efficiency | ≥90%@AC |
| Dimensions( L*W* H) | 1280*1000*2400mm |
Weight | 2400kg |
IP Grade | IP55 |
Temperature range | -20-50℃ |
Humidity range | ≤95% (non -condensing) |
Maximum working altitude | 2000m (＞ 2000m need to derate) |
Battery temperature control method | Liquid cooling |
Fire fighting system | Aerosol/perfluorohexanone |
System communication protocol | Modbus -RTU/TCP |
Certified | GB/36276 |
Cell parameter | |
Rated capacity | 280Ah |
Rated energy | 896Wh |
Dimensions | 71*173*207mm |
Battery box parameter | |
Grouping | 1P30S |
Nominal voltage | 96V |
Nominal energy | 26.88kWh |
Dimensions | 1089.5*485*245mm |
Weight | 200kg |
System composition | |
Battery system | 8 sets of the battery box |
BMS management system | 1 set |
Fire fighting system | 1 set， customizable |
Liquid Cooler | 1 set，3kW |
Cabinet | 1 set |
PCS | 1set， 100kW |
Distribution box | 1 set |
Item Highlight
- Support on-grid and off-grid (customizable)
- Equipped with a fire protection system
- Liquid cooling balance temperature prolongs the life cycle
- The electrodes and busbars are designed with plastic slots to prevent leakage
- Competitive Price (Order large quantity of this system, contact the salesman to get the lowest price )
