Seplos 48V 280Ah LiFePO4 Lithium Iron Phosphate Battery Pack With Smart BMS Energy Storage MASON 280
MASON-280
If you want wholesale price, please do not hesitate to contact us.
minimum order
1 unit
Supply Ability
10000unit / Month
Country of Origin
China
Stock Time
15-20Day
Quantity:
This Mason 280 battery solution is Suitable for 280Ah lithium iron phosphate battery cells, which can use 16 pieces in series to offer 14336wh power loading.
The complete pack can be widely used in renewable energy, industrial applications, and marine industries. The 24V solution is also available. Explore here to learn more about the 24V lithium battery.
Features
- Automotive-grade lithium battery
- Safer use
- Plug-and-play compatibility
- Passive balancing
- Bluetooth monitoring
- Scalable energy storage
Technical specifications
Nominal Voltage:48V /51.2V
Rated capacity: 280Ah/14kwh
BMS: Smart 16S 200A (Max 32pcs In Parallel)
Communication protocol: CAN / RS485*2
Power: 14336Wh
Cycle Life: >6000 Cycles
Max. Charging Current: 200A
Max. Discharge Current: 200A
Waterproof class. : IP20
Battery Size:(L*W*H)817*412*267mm
Weight: 113kg
Display: LCD Screen
Built-in battery management system.
CAN/RS485*2 inverter communication.
Nominal Voltage:48V /51.2V
Rated capacity: 280Ah/14kwh
BMS: Smart 16S 200A (Max 32pcs In Parallel)
Communication protocol: CAN / RS485*2
Power: 14336Wh
Cycle Life: >6000 Cycles
Max. Charging Current: 200A
Max. Discharge Current: 200A
Waterproof class. : IP20
Battery Size:(L*W*H)817*412*267mm
Weight: 113kg
Display: LCD Screen
Built-in battery management system.
CAN/RS485*2 inverter communication.
| Item | Specifications |
Rated energy(kWh) | 14.3KWh |
| Configuration | 1P16S |
| Nominal Voltage(V) | 51.2V |
| Nominal Capacity(Ah) | 280Ah @0.5C discharge current 25±2℃ |
| Discharge Cut-off Voltage (V) | 41.6V |
| Standard charge/discharge Current (A) | 140A @25±2℃ (Recommended) |
| Max Standard charge/discharge Current (A) | 200A @25±2℃ |
| Working Temperature | 0～50℃(Charge) -10～50℃(Discharge) |
| Weight(Kg) | 112Kg±5kg |
| Dimension(mm) | (750)×(440)×(251)mm |
| Recommended SOC Range | 15-95% |
| Communication mode | CAN (Default)or RS485 |
Low Voltage 48V Energy Storage Solution - Suitable Inverters
| Brand | Protocol | Communication | Versions |
| Pylontech | CAN-Bus-Protocol-PYLON | CAN | V1.3 |
| Goodwe | Goodwe Communication Protocol | CAN | V1.5 |
| Lolis | CAN Communication Protocol | CAN | V1.0 |
| Sofar | BMS CAN BUS Protocol | CAN | V1.0 |
| SMA | FSS-ConnectingBat-TI-EN-20W | CAN | V2.0 |
| Victron | Can-Bus_Bms_Protocol | CAN | V1.0 |
| LUXPOWER | Luxpowertek Battery CAN Protocol | CAN | V1.0 |
| Studer | Technical Specification Studer BMS Protocol | CAN | V1.03 |
| TBB | TBB BMS CAN Communication V1.02 | CAN | V1.02 |
| Deye | CAN-Bus-Protocol-PYLON-V1.3 | CAN | V1.0 |
| Sorocec | 2_CAN Protocol 1.0 | CAN | V1.0 |
| MEGAREVO | Hybrid Inverter_5K_BMS Protocol V1.01 | CAN | V1.01 |
| Amensolar | CAN-Bus-Protocol-PYLON | CAN | V1.0 |
| MUST | PV1800F-CAN Communication Protocol | CAN | V1.04.04 |
| AFORE | Luxpowertek Battery CAN Protocol | CAN | V1.0 |
| Pylontech | RS485-Protocol-Pylon-Low-Voltage | 485 | V3.5 |
| Voltronic Power | Voltronic Inverter And BMS 485 Communication Protocol | 485 | V1.0 |
| SRNE | PACE BMS Modbus Protocol For RS485 | 485 | V1.3 |
| Deye | RS485-Protocol-Pylon-Low-Voltage | 485 | V1.0 |
